VIO X205-100 (dBTechnologies)

2 Yollu Aktif Hoparlör LF:2x5”,HF: 1,”, 400 Watt

Teknik Özellikleri



2 Yollu Aktif Hoparlör

ACOUSTICAL DATA

Usable bandwidth [-10dB]75 - 21.000 Hz

Frequency Response [-6dB]80 - 20.000 Hz

Max SPL126 dB

HF1x 1”, 1.4 v.c.

LF2x 5”, 1" v.c

VIO X205-60 Directivity60° x 60°

VIO X205-100 Directivity100° x 100°



AMPLIFIER

Amplifier400 W RMS Class-D Digipro® G3

CoolingConvection

Power SupplyAuto-range SMPS



PROCESSOR

ControllerDSP 28/56 bit

AD/DA Converter24 bit/48 kHz

LimiterPeak, RMS, Thermal

ProcessingFIR Linear Phase Filters



INPUT

Signal Input1 x XLR balanced, 1 x RJ45 Link (RDNet), 1x USB (Data Service)

Signal Output1x XLR balanced, 1 x RJ45 Link (RDNet)

Power Socket1x PowerCON TRUE1 In

1x PowerCON TRUE1 Out

Controls1x Rotary Encoder (8x EQ presets)

1x Input Attenuation Rotary Switch

1x On LED

1x Status LED

1x Signal LED

1x Limiter LED



MECHANICS

HousingWooden Cabinet, Polyurea painting

Handles1x (top)

Wedge AngleMonitor Use 5°

Rigging points2x M10 Threaded Nuts (top and bottom)

Width150 mm (5.9 in)

Height485 mm (19 in)

Depth240 mm (9.4 in)

Weight7.8 kg (17.2 lbs)
