DN-300ZB (DN-300ZB)

CD: CD-DA (CD-TEXT), CD-ROM (ISO9660), CD-R, MP3-CD

USB: FAT16 / FAT32

SD/SDHC: FAT16 / FAT32

Extension: WAV

Bitrate: 16–bit

Samplig Frequency: 44.1 kHz

Extension: M4A

Compression method: AAC-LA

Bitrate: 32 to 320 kbps and VBR

Sampling Frequency: 44.1 kHz

Extension: MP3

Bitrate: 32 to 320 kbps and VBR

Sampling Frequency: 44.1 kHz

Number of channels: 2 (stereo), 1 (mono)

Audio frequency characteristics: 20 Hz - 20 kHz (± 1.0dB)

S/N ratio: More than 95 dB (A-Weighted)

Total harmonic distortion: Less than 0.01%

Dynamic Range: More than 85 dB

Channel Separation: More than 80 dB

Bluetooth

Version 3.0

Output Class 2

Range: Up to 100 feet (30m) with included antenna

Supported Codec: SBC, MP3, AAC, aptX

Supported Profiles: A2DP, AVDTP 1.0, AVCTP 1.3, AVRCP 1.0, SSP

Device memory: Recall up to 8 pairings instantly

Input

Aux in: TRS (3.5mm)

Input impedance: Over 10 kΩ

Maximum input level: 1 Vrms

Maximum output level: 3 Vrms

Output

Load impedance: Over 10 kΩ

Output level: 2 Vrms at 10 kΩ load

Output Level: +8 dBu

Load impedance: > 10 kΩ

Tuner

FM receiving range: 87.5 MHz - 107.9 MHz

AM receiving range: 522 kHz - 1710 kHz

Operating Environment

Operating temperature: 5-35 degrees Celcius (41-95 degrees Fahrenheit)

Operating humidity: 25-85%, no condensation

General

USA & Canada: AC 120V, 60 Hz

EU, UK, APAC: AC 230V, 50/60 Hz

Japan: AC 100V, 50/60 Hz

Power consumption: 30W

Dimensions: 19” x 13.7” x 1.73” (483 x 347 x 44mm) with rack ears

Weight: 7.94 lbs. / 3.6 kg

Others

Max storage capacity: Up to 2TB

Max file size: 2 GB

Max number of files per folder: 999

Max number of folders: 999

Max folder heirarchies: 8

Max file/folder name length: 255 characters
