TEKNİK ÖZELLİKLER

Mixing capability

Mixing channels         16 Line Inputs (8 mono and 4 stereo)

GROUP          4 GROUP Buses + ST Bus

AUX   2 AUX Sends + 2 FX Sends

Input channel functions         Compressor CH1-8,HPF(100Hz 12dB/oct), CH EQ(MONO) ±15dB(Max.):High 8kHz shelving/ Mid 250Hz-5kHz peaking(CH1-8,13-16)/ Low 125Hz shelving, CH EQ(STEREO) ±15dB(Max.):High 8kHz shelving/ Mid 2.5kHz peaking(CH9-12)/ Low 125Hz shelving

On-board processors  FX1:REV-X(8 PROGRAM, PARAMETER control), FX2:SPX (16 PROGRAM, PARAMETER control)

I/O

Mic inputs       MIC: 10

Phantom power          48V phantom power per channel

Line inputs      LINE: 8mono+4stereo, CH INSERT: 8, RETURN: 1stereo, 2TR IN: 1 stereo

Digital I/O      USB Audio USB IN/OUT: iPod, iPhone exclusive

General specifications

Total harmonic distortion       0.02% (20Hz-20kHz@ +14dBu)

Frequency response    +0.5/-1.0dB 20Hz - 20kHz, refer to the nominal output level @1kHz

Equivalent input noise           -128 dBu (20Hz–20 kHz, Rs=150Ω, Input Gain = Maximum)

Residual output noise -102 dBu (20Hz–20 kHz, Rs=150Ω, Input Gain = Maximum)

Crosstalk         -74dB @ 1kHz

Power requirements    100-240V 50Hz/60Hz

Power consumption    55W max

WxHxD          447x143x495

Net weight      9.0kg
