| LF DRIVER SIZE |
203mm (5") |
| HF DRIVER SIZE |
25mm (1") |
| HF DRIVER TYPE |
Soft dome |
| Crossover |
1725Hz 4th order acoustic Linkwitz-Riley |
| OK FOR USE NEAR MAGNETICALLY SENSITIVE EQUIPMENT |
 |
| INPUT SENSITIVITY (-10dBV INPUT) |
92dB / 1m |
| Power Configuration |
Bi-amplified |
| HF DRIVER POWER AMP |
41W, Class-D |
| LF DRIVER POWER AMP |
41W, Class-D |
| FREQUENCY RESPONSE (±3dB) |
49Hz – 20kHz |
| Frequency Range (-10dB) |
43Hz – 24kHz |
| LOW FREQUENCY EXTENSION (-10dB) |
43Hz |
| MAXIMUM CONTINUOUS SPL |
94dB |
| Maximum Peak SPL |
108dB |
| MAXIMUM PEAK INPUT LEVEL(-10dBV / +4dBu) |
+6dBV / +20.3dBu |
| SYSTEM DISTORTION CRITERIA |
<10% THD at maximum output with full compressor / limiter engagement |
| ELECTRICAL DISTORTION CRITERIA |
0.2% THD @ 1kHz / 2.83VRMS output; <1% THD @ 1kHz, full rated output |
| Signal to Noise Ratio |
75dBA (A-Weighted), 70dBr (unweighted), relative to 2.83VRMS output |
| COVERAGE HORIZONTAL x VERTICAL |
120° x 90° |
| ANALOG INPUT TYPES |
1 x XLR female, 1 x TRS female, balanced |
| HF TRIM CONTROL |
-2dB, 0dB, +2dB |
| BOUNDARY EQ |
LF Shelf @ 50Hz: -3dB, -1.5dB, 0dB |
| AC INPUT VOLTAGE |
100 – 240VAC (±10%), 50 / 60Hz |
| ENCLOSURE TYPE |
Ported |
| ENCLOSURE CONSTRUCTION |
15mm MDF |
| ENCLOSURE FINISH |
Matte black PVC |
| BAFFLE CONSTRUCTION |
Injection-molded structural ABS |
| CABINET DIMENSIONS (H x W x D) |
298 x 185 x 231 mm (11.75" x 7.3" x 9.9") |
| DISPLAY CARTON (H x W x D) |
354 x 244 x 299mm (13.9" x 9.6" x 11.8") |
| SHIPPING CARTON (H x W x D) |
373 x 260 x 315mm (14.7" x 10.2" x 12.4") |
| Net Weight |
4.73 kg (10.43 lbs) |
| SHIPPING GROSS WEIGHT |
5.72 kg (12.61 lbs) |
